Description
The Ruijie Reyee RG-NBS5300-8MG2XS-UP is a premium enterprise-class Layer 3 cloud-managed multi-gigabit PoE switch built for high-density Wi-Fi 6/6E deployments, enterprise networks, smart campuses, hotels, hospitals, data-intensive offices, and advanced surveillance infrastructures. Designed to meet the growing demand for ultra-fast network access, this switch combines multi-gigabit Ethernet performance, powerful PoE output, intelligent cloud management, and advanced Layer 3 routing capabilities into a compact professional-grade platform.
The switch features 8 multi-gigabit 100M/1G/2.5G PoE++ Ethernet ports and 2×10G SFP+ uplink ports, allowing high-speed connections for next-generation wireless access points, NAS storage systems, workstations, IP cameras, and backbone aggregation. This architecture ensures exceptional bandwidth efficiency for modern enterprise applications where standard Gigabit switching is no longer sufficient.
With a high PoE power budget of 240W, the RG-NBS5300-8MG2XS-UP can power multiple Wi-Fi 6 access points, PTZ surveillance cameras, VoIP devices, and IoT infrastructure directly through Ethernet, eliminating the need for additional power adapters and simplifying deployment.
The switch delivers advanced Layer 3 routing features including static routing, VLAN segmentation, inter-VLAN routing, ACL-based traffic filtering, QoS prioritization, multicast optimization, and intelligent redundancy mechanisms. These capabilities provide secure traffic isolation, optimized bandwidth distribution, and scalable enterprise-grade network performance.
Integrated with Ruijie Reyee Cloud Management, the device enables centralized remote configuration, topology visualization, firmware upgrades, health monitoring, and intelligent fault diagnostics through mobile app or cloud dashboard. This dramatically reduces operational complexity and makes enterprise-scale deployment easier and more efficient.
Built with industrial-grade surge protection, intelligent cooling, and long-term hardware stability, the RG-NBS5300-8MG2XS-UP ensures continuous reliable operation in demanding environments requiring 24/7 performance.
| Specification | Details |
|---|---|
| Product Model | RG-NBS5300-8MG2XS-UP |
| Product Type | Layer 3 Cloud Managed Multi-Gigabit PoE Switch |
| Access Ports | 8 × 100M/1G/2.5G RJ45 PoE++ |
| Uplink Ports | 2 × 10G SFP+ |
| PoE Standard | IEEE 802.3af / at / bt |
| PoE Budget | 240W Total |
| Switching Capacity | 80 Gbps |
| Packet Forwarding Rate | 59.52 Mpps |
| MAC Address Table | 16K |
| Layer Support | Layer 2 / Layer 3 Static Routing |
| VLAN Support | Up to 4094 VLANs |
| Routing Features | Static Routing / Inter-VLAN Routing |
| QoS | 802.1p / DSCP / Queue Scheduling |
| ACL Support | Advanced Access Control Lists |
| Multicast | IGMP Snooping / MLD Snooping |
| Link Aggregation | LACP Supported |
| STP Protocols | STP / RSTP / MSTP |
| Surge Protection | 6kV |
| Cloud Management | Reyee Cloud / Mobile App / Web Dashboard |
| Cooling System | Intelligent Smart Fan |
| Power Supply | AC 100–240V |
| Operating Temperature | 0°C to 50°C |
| Dimensions | 440 × 300 × 44 mm |
| Mounting Type | Standard 1U Rack Mount |
| Weight | Approx. 4.8 kg |
| Warranty | 3 Years (Region dependent) |
