Description
The Ruijie Reyee RG-EST310 V2 is a professional outdoor point-to-point (PTP) and point-to-multipoint (PTMP) wireless bridge designed for CCTV transmission, building-to-building connectivity, campus networks, elevator surveillance systems, and long-distance wireless data backhaul. It uses 5GHz Wi-Fi 5 (802.11ac) dual-stream technology and delivers wireless speeds of up to 867Mbps, ensuring stable and high-performance data transmission over long distances such as up to 1KM or more depending on environment conditions.
This device is widely used in professional networking scenarios where cabling is difficult or expensive, such as factories, warehouses, industrial zones, remote buildings, and outdoor surveillance setups. It comes pre-paired from the factory, allowing plug-and-play deployment, which significantly reduces installation time and configuration complexity.
Built with a rugged outdoor design, the RG-EST310 V2 features IP54 weather resistance, making it suitable for operation in harsh environments including dust, rain, and temperature fluctuations from -30°C to +55°C. It also includes intelligent management features through the Reyee Cloud platform, enabling remote monitoring, device reboot, and easy maintenance without requiring complex local controllers.
With its stable long-range performance, strong interference resistance, and easy deployment, the RG-EST310 V2 is an excellent choice for wireless CCTV transmission and outdoor network extension projects where reliability and cost-efficiency are essential.
| Specification | Details |
|---|---|
| Product Model | RG-EST310 V2 |
| Product Type | Outdoor Wireless Bridge (PTP/PTMP) |
| Wireless Standard | IEEE 802.11ac / 802.11n |
| Wireless Technology | Wi-Fi 5 Dual-Stream |
| Maximum Wireless Speed | 867 Mbps |
| Frequency Band | 5GHz |
| Radio Design | Single Radio |
| Spatial Streams | 2 Streams |
| MIMO Technology | 2×2 MIMO |
| Antenna Type | Built-in Directional Antenna |
| Channel Width | 20 / 40 / 80 MHz |
| Ethernet Port | 1 × Fast Ethernet (FE) |
| Power Supply | Passive PoE |
| Maximum Power Consumption | ~8–10W |
| Operating Mode | Base Station / CPE |
| Pairing Mode | Factory Pre-Paired |
| Management | Ruijie Reyee Cloud |
| Bridge Tools | Signal alignment, spectrum scan |
| PTMP Support | Yes |
| Operating Temperature | -30°C to +55°C |
| Protection Rating | IP54 |
| Mounting Type | Pole / Wall Mount |
| Dimensions | ~147 × 76 × 37 mm |
| Use Case Distance | Up to 1KM+ (environment dependent) |
