Description
The Ruijie Reyee RG-RAP1260 is a high-performance Wi-Fi 6 AX3000 wall-mounted access point built for modern hotels, offices, apartments, dormitories, smart homes, and enterprise indoor networking environments. Designed with advanced IEEE 802.11ax technology, this wall plate access point delivers combined wireless speeds of up to 2974Mbps, ensuring ultra-fast internet performance for streaming, online meetings, cloud applications, gaming, and large-scale wireless connectivity.
It features dual-band 2×2 MU-MIMO architecture with 573Mbps on 2.4GHz and 2401Mbps on 5GHz, supporting 160MHz channel width for maximum wireless efficiency and faster device connections. The intelligent band steering and load balancing technology automatically optimizes traffic distribution to deliver stable and low-latency performance even in high-density environments.
The RG-RAP1260 comes equipped with 5 Gigabit Ethernet ports, including 1 rear uplink PoE input port and 4 downlink LAN ports, making it ideal for connecting wired devices such as IPTV, IP phones, desktop PCs, smart TVs, and other network-enabled devices directly from the wall panel. This multi-port design makes it highly suitable for hotel guest rooms and professional office deployments.
Its compact ultra-slim wall-mount design fits standard mechanism boxes for quick and clean installation while maintaining a premium modern appearance. Built-in Reyee Mesh support, 802.11k/v/r roaming, cloud portal authentication, and centralized Ruijie Cloud management make deployment, monitoring, optimization, and maintenance simple for IT administrators and business owners.
| Specification | Details |
|---|---|
| Product Model | RG-RAP1260 |
| Product Type | Wall Plate Wi-Fi 6 Access Point |
| Wi-Fi Standard | IEEE 802.11ax / ac / n / g / b |
| Wireless Speed | Up to 2974 Mbps |
| 2.4GHz Speed | 573 Mbps |
| 5GHz Speed | 2401 Mbps |
| Channel Width | Up to 160MHz |
| MIMO Technology | 2×2 MU-MIMO (Dual Band) |
| Radio Design | Dual-radio, 4 Spatial Streams |
| Integrated Antenna | Built-in Omnidirectional |
| Antenna Gain | 2.4GHz: 3dBi / 5GHz: 5dBi |
| Ethernet Ports | 5 × 10/100/1000Mbps |
| Rear Uplink Port | 1 × Gigabit PoE In |
| Downlink Ports | 4 × Gigabit LAN |
| Power Supply | IEEE 802.3af / 802.3at PoE |
| Power Consumption | ≤12W |
| Concurrent Clients | Max 512 / Recommended 110 |
| Supported SSIDs | Up to 8 |
| Security | WPA-PSK / WPA2-PSK |
| Mesh Networking | Supported |
| Roaming Protocol | 802.11k/v/r |
| Cloud Management | Supported |
| Management Modes | Web / Cloud / App / Console |
| IPv6 Support | Yes |
| Operating Temperature | 0°C to 40°C |
| Protection Rating | IP41 |
| Dimensions | 1 |
