Description
The Ruijie Reyee RG-RAP6260(H) is a powerful enterprise-grade Wi-Fi 6 (802.11ax) AX6000 outdoor omni-directional access point designed for large-scale high-density wireless environments such as stadiums, campuses, public squares, parks, industrial zones, logistics hubs, smart cities, and enterprise outdoor networks. It delivers ultra-high wireless performance with a total throughput of up to 5.95Gbps, ensuring extremely fast, stable, and low-latency connectivity even in heavily crowded outdoor scenarios.
Built with advanced Wi-Fi 6 technologies including OFDMA, 1024-QAM, and 4×4 MU-MIMO on both bands, this device significantly improves spectral efficiency and multi-user capacity. It is specially engineered to handle high-density simultaneous connections, making it ideal for mission-critical outdoor deployments where performance stability is essential.
The RG-RAP6260(H) features a fully sealed industrial-grade design with IP68 protection, ensuring reliable operation in extreme weather conditions such as heavy rain, dust, humidity, wind, and high/low temperatures. It supports a wide operating range from -40°C to +65°C, making it suitable for harsh outdoor environments.
For high-performance backbone connectivity, it includes a 2.5GbE uplink port and 1× SFP fiber port, enabling long-distance fiber transmission up to 20km, ideal for campus or distributed enterprise networks. Combined with Ruijie Cloud management, Reyee Mesh, and intelligent RF optimization, it provides centralized control and easy large-scale deployment.
| Specification | Details |
|---|---|
| Product Model | RG-RAP6260(H) |
| Product Type | Outdoor Omni-Directional Access Point |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Wireless Technology | AX6000 High Density Wi-Fi 6 |
| Maximum Wireless Speed | 5950 Mbps |
| 2.4GHz Speed | 1147 Mbps |
| 5GHz Speed | 4803 Mbps |
| MIMO Technology | 4×4 MU-MIMO (Dual Band) |
| Spatial Streams | 8 Streams |
| Antenna Type | Built-in High-Gain Omni Antennas |
| Ethernet Ports | 1 × 2.5GbE RJ45 + 1 × 1GE SFP |
| Fiber Support | Up to 20km (via SFP) |
| Power Supply | PoE / PoE+ / DC Power |
| Maximum Power Consumption | ~40W |
| Maximum Clients | Up to 512+ users |
| Cloud Management | Supported |
| Reyee Mesh | Supported |
| Operating Temperature | -40°C to +65°C |
| Protection Rating | IP68 |
| Mounting Type | Wall / Pole Mount |
| Dimensions | 300 × 300 × 75.5 mm |
| Weight | ≤ 3.5 kg |
